Oxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance Wire

Brand Name : KAIXIN

Model Number : KX-Alloy686

Certification : ISO9001:2015

Place of Origin : China

MOQ : 200KG

Price : To negotiate

Payment Terms : T/T, L/C

Supply Ability : 50~80 TONS per MONTH

Delivery Time : 45~60days

Packaging Details : Wooden Box, size as per guests' request

Shape : Wire,Strip,Rod,Pipe,Plate

Alloy Type : Nickel-based Deformed Superalloy

Raw Materials : NI Rem%,CR19-23%,MO15-17%

Executive standard : ASTM

Delivery State : Sosoloid

Application : Applications for resistance to corrosive medium in chemical processing, pollution control, pulp,paper manufacturing and waste management.

Features : Corrosion resistance and oxidation resistance

Size : Negotiable

Contact Now

KX Inconel 686 Nickel Alloy Wire Round Bar Tube Steel Sheet Light Rod on Inconel Alloy

Product Description and Application

Inconel 686 is also known as UNS N06686, W.N.2.4606

Inconel 686 is a single-phase austenitic Ni-Cr-Mo-W alloy with excellent corrosion resistance and reduction resistance in a range of harsh environments. Oxidizing medium that helps resist local corrosion,such as pitting. It can be made into pipes and storage tanks, reactors and heat exchangers, as well as offshore oil well production equipment.

Process Performance and Requirements

  • Product Fusion Process

Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)

  • Product Chemical Composition

Cr Mo W Ti Fe C Mn S Si P Ni
19-23 15-17 3.0-4.4 0.02-0.25 ≤1.0 ≤0.01 ≤0.75 ≤0.02 ≤0.08 ≤0.04 Rem

  • Product Physical Property

Density 8.4g /cm³
Melting Point

1370-1420℃

  • Product Mechanical Property

Tensile Strength 550 MPa

Yield Strength

(0.2% Offset Yield Point)

 240 MPa
Elongation 35%
  • Productive Process

Oxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance Wire

  • Professional Customization

Cold-drawn Wire ¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire ¢5.5~¢20mm(Delivery in rolls)
Strip thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe

¢60~350mm,L800-2500mm
Hot-rolled Burnishing ¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing ¢2.5~18mm,L1000-8000mm
Seamless Tube ¢1~275mm,wall thickness 0.2~30,L1000-8000mm

Oxidation Resistance 686 Inconel Alloy Bar Tube Sheet Nickel Chromium Resistance Wire
